Photonic subsystem electronics, assembled from a proven building-block library
DIPPS™ — Dynamic Inline Photonic Pluggable Subsystems — is our platform for photonic integrated circuit control and management: a defined board form factor plus a library of pre-verified functional building blocks, including TEC control, laser driver control, bias control (single- and multi-modulator), lock-in phase amplifiers, lock-in phase-sensitive detection, FPGA/DDR3 network, and ADC/DAC front-ends.
✓ TEC control
✓ Laser driver control
✓ Bias control (single- and multi-modulator)
✓ Lock-in phase amplifiers
✓ Lock-in phase-sensitive detection
✓ FPGA/DDR3 network
✓ ADC/DAC front-ends
✓ Form factor: defined DIPPS™ board
✓ Building blocks: pre-verified function library
✓ Delivered with: firmware, control software and mechanical integration
A photonic integrated circuit needs substantial electronic, firmware and thermal infrastructure before it becomes a usable subsystem. Building that infrastructure from a blank sheet for every new PIC or application is slow and expensive. DIPPS™ shortens that path by starting from proven, verified designs rather than a fresh design exercise each time.
This is where PIC n Mix comes in: you choose the function set assemble and verify a board from our building-block library inside the DIPPS™ form factor, then deliver matching firmware, control software and mechanical integration.
01
You choose the function set your subsystem needs (TEC control, bias control, lock-in detection, laser driver control, in whatever combination the application calls for)
02
We assemble and verify a board from our building-block library inside the DIPPS™ form factor
03
Then deliver matching firmware, control software and mechanical integration
01
Faster time-to-demonstrator than a bespoke design
02
Lower non-recurring engineering cost, drawing on designs already built and verified
03
Access to circuit designs proven across multiple funded international R&D programmes
Through our European and UK R&D collaborations we have developed and proven DIPPS™ test platforms for a variety of applications including AI networks and hyperscale data-centre networks, quantum communication, space communication and gas sensing, among others. Please contact us to find out more.
Figure 1: DIPPS™ platform for Quantum communication PIC developed on InnovateUK EQUINOX project includes TEC control, bias control, FPGA/DDR3, APDs, laser drivers, voltage switches and other advanced functions
